T488mm-D
【 Rated conditions】
|
No. |
Item |
Specification |
|
1 |
Operating Voltage |
30Vp-p Square Wave /max. |
|
2 |
Operating Temperature Range |
-20 ~ +70℃ |
|
3 |
Storage temperature range |
-30 ~ + |
【 Electrical Characteristics】
|
No. |
Item |
Specification |
|
1 |
Sound Pressure Level |
Min 73dB at 12.0Vp-p/0.8KHz/10cm |
|
2 |
Capacitance at 100Hz |
66000pF ± 30% |
